A: ALAS provides high-grade 42CrMo (HRC 47–52) or Cr12MoV (HRC 58–62) tools for diverse metals, with optional PVD coatings (TiN/TiAlN) and PU films to ensure scratch-free results.

• Aluminum & Mild Steel: Handled with standard hardened tools.

• Stainless & High-Strength Steel: Specialized, wear-resistant options are available.

⚠️ Technical Note: For high-strength or thick plates, contact our team to select the correct V-opening and tonnage, preventing tool cracking.

[Contact Our Engineers to Match Your Material Specs]

As a direct manufacturer, ALAS specializes in OEM/ODM custom tooling tailored to your specific geometries.

• Capacities: Up to 6,000mm length, 250 Ton/meter load, and ±0.02mm precision via CNC grinding.

• Capabilities: Custom acute/obtuse angles, large radii, special offset channels, and complex multi-stage tools.

  [Submit Your 2D/3D Drawings (STEP/IGES/DWG) for a Free Feasibility Simulation]

ALAS is a one-stop professional manufacturer offering complete press brake tooling solutions. Our high-precision dies and punches fit all mainstream clamping standards, sorted into three core product groups below:

1. Upper Tools (Punches)

• Straight Punches: Standard, acute-angle and heavy-duty variants

• Gooseneck Punches: Reserved for deep clearance bending and U-channel fabrication

• Acute Angle Punches: 30°, 45°, 60° specifications available

• Segmented / Sectional splicable punches

2. Lower Tools (Dies)

• Single V-Dies & Double V-Dies

• Multi-V Die Blocks (multi-groove general-purpose blocks)

• 4-Way Multi-angle Die Blocks

• Acute & Obtuse Angle Dies: 30°, 45°, 60°, 120° options

3. Specialized Custom Forming Tooling

• Hemming & Flattening Tools: For edge finishing and sheet metal joining

• Radius Tooling & Matching Holders: For smooth arc bending operations

• Custom Profile Forming Tools: Built fully to your component technical drawings

The gap between the two types mainly comes from manufacturing precision, surface quality and compatibility with CNC bending equipment. ALAS adheres to strict production standards to deliver stable, reliable bending results:

Precision-Ground Tooling

Our premium grade tooling features ultra-tight dimensional tolerances of ±0.01mm ~ ±0.02mm. All key mounting, joint and forming surfaces are fully finished via CNC grinding.

Segments can be combined arbitrarily without extra manual calibration, effectively removing seam lines and inconsistent bending angles on workpieces.

It is the ideal choice for CNC press brakes, high-tolerance electrical cabinets, automotive stamped parts and mixed-variety production lines.

Notably, every standard tool from ALAS is fully precision ground.

Planed (Milled) Tooling

Produced via conventional planing or heavy milling processes, this tool only achieves loose tolerances of ±0.05mm or higher.

Poor dimensional uniformity means these tools must be used as whole full-length pieces; splicing separate sections will easily cause uneven height alignment.

It is only fit for ordinary non-CNC press brakes, low-accuracy forming tasks or simple thick structural plate bending.

Outfitting your press brake with ALAS precision-ground tooling drastically cuts down setup time, rejects from repeated test bends, and fully unlocks the performance potential of your CNC bending control system.

The core distinction comes down to production flexibility and setup speed. ALAS supplies both styles to suit different production volumes and bending demands:

Segmented (Sectional) Tooling

Supplied as matched kits of interchangeable standard lengths. A typical 835mm set includes 100mm, 50mm, 25mm, 20mm, 15mm and 10mm segments; standalone 415mm and 835mm single sections are also available.

ALAS maintains ultra-tight precision tolerances of ±0.02mm across all sectional pieces. Segments can be freely assembled to hit any target bending length with zero manual alignment required.

Perfect for box bending, intricate 3D formed parts, and small-batch jobs with frequent part specification changes. Another key advantage: only the damaged individual segment needs replacement instead of the whole set, cutting long-term maintenance expenses significantly.

Full-Length (Integral) Tooling

Machined as one solid continuous piece, with lengths ranging up to 4000mm or 6000mm based on your press brake capacity.

Solid full-length dies deliver superior overall structural rigidity and leave no spliced seam marks on finished sheet metal. This option is strongly recommended for long, heavy-gauge straight bending applications that require high tonnage spread across a wide forming surface.

All ALAS segmented tools feature precision ground mating contact surfaces, guaranteeing perfectly seamless, accurate alignment when sections are assembled on your press brake.

The right punch type is determined by the bending clearance needs of your workpiece. Our ALAS engineering team shares clear selection guidance below:

Straight Punch (Standard / Acute Tip)

The universal choice for regular 90° bends and wide obtuse-angle forming.

Its solid vertical construction delivers superior rigidity and maximum load-bearing capacity. ALAS straight punches are the top pick for heavy-gauge, simple sheet metal bending jobs.

Gooseneck Punch

Built with a deep recessed throat to eliminate workpiece collision during bending.

This punch is mandatory for fabricating U-channels, multi-bend complex components, deep box parts, and workpieces with pre-folded return flanges — pieces that would otherwise crash into a standard straight punch body.

Unsure which punch fits your part geometry?

Submit your 2D or 3D bending drawings to ALAS. Our technical team will conduct professional bending simulations to recommend or customize the optimal punch profile for your application.

ALAS press brake tooling is precision engineered for full plug-and-play fit with almost all globally recognized press brake manufacturers.

Our dies and punches work flawlessly on CNC and conventional press brakes including Amada, Trumpf, Accurpress, Bystronic, LVD, Wila, Cincinnati, Yawei and more.

We cover every widely used standard tool shank type:

• European / Promecam Style

• Wila New Standard Style

• American Style

• Trumpf 20mm / 90° Tool System

If you own standard production equipment or need custom clamping adapters for unique machinery, ALAS offers fully bespoke tool fabrication tailored to your exact machine specifications.

Three global mainstream clamping standards are widely adopted across the metal fabrication industry, with distinct structural features as below:

1. American Style

   Built with a classic fixed tang structure. Tools are fastened via single-side clamping plates and manual tightening bolts.

2. European / Promecam Style

   Identifiable by a unique safety groove machined on upper dies. It uses quick-change clamping slots that lock tools firmly to avoid accidental falling.

3. Wila / Trumpf Style

   High-end symmetrical clamping design. It delivers automatic self-centering and precise alignment, paired with safety snap pins for rapid vertical tool installation.

Simple Ways to Confirm Your Machine’s Clamping Type

1. Refer to your original press brake operation manual;

2. Measure the exact size of your existing tool tang or clamping slot;

3. Take clear close-up photos of your current tool cross-section and send them to ALAS.

We produce premium press brake tooling fully interchangeable with all three standard systems. Custom special clamping profiles are also available upon submission of your technical drawings.

Reverse-Engineering Tooling for Legacy Ironworkers

Mitigating single-station downtime on vintage structural fabrication equipment becomes critical when original equipment manufacturers (OEMs) permanently cease component reproduction support. To break this supply deadlock, ALAS Machinery provides specialized, non-destructive reverse-engineering services custom-tailored to replicate tooling for legacy or decommissioned hydraulic ironworker models through three adaptive engineering methodologies:

• Degraded Document Restoration: We can reconstruct and cross-reference exact tooling geometries from historical physical drawings, weathered schematics, or faded blue-prints.

• Legacy Sample Measurement: Our metrology department utilizes precision calipers and non-destructive 3D scanning technology to replicate dimensions from worn or fractured tooling samples sent to our facility.

• Zero Minimum Order Quantity (No MOQ): To alleviate immediate station out-of-service bottlenecks without inflating your operational overhead, we maintain an on-demand manufacturing flow—with zero minimum batch constraints. We happily produce individual custom punches or single lower dies.

Every individual legacy component is manufactured under identical structural tolerances and from premium tool steels as our mass-production configurations, ensuring a zero-play fitment. Please submit your available physical data or engineering notes to our estimation division for an absolute technical evaluation.

➔ Check out our legacy machine custom tooling service

Punch Chip & Damage Assessment

Evaluating whether a degraded compression tool can be safely salvaged requires specific mapping of macro-defects relative to the component's underlying stress zones. To facilitate precise on-site inspection before scheduling maintenance, the technical support division at ALAS Machinery establishes three primary criteria for field assessment:

• Minor Edge Chips (< 1mm): Surface defects limited to less than 1mm along the outer cutting perimeter can typically be restored through standard precision grinding, provided total material removal does not exceed our specified 3mm lifetime threshold.

• Severe Fractures or Longitudinal Cracks: If a localized chip or propagating fatigue crack extends upward into the structural body or tool shank, the component must be decommissioned immediately to prevent catastrophic in-stroke failure.

• Shank or Seating Face Defect: Operating press tooling with damage to its mounting or indexing surfaces disrupts precise alignment matrices, introducing uneven lateral loading and inducing severe scoring inside the machine ram.

If your quality team is uncertain regarding localized microstructural integrity, please forward high-resolution orthographic photographs of the wear zone to our application engineering center. Our technicians will cross-reference the defect geometry to determine the feasibility of a precision regrind or issue a replenishment part number.

➔ Send us photos for a free regrind assessment

Punch Lubrication Guidelines

Implementing strategic boundary lubrication throughout high-frequency press strokes reduces interfacial friction and controls severe temperature spikes across the shear zone. To maximize tool steel longevity and secure excellent piece-part hole finish, the engineering advisors at ALAS Machinery define three mandatory shop-floor lubrication directives:

• Carbon Steel & Stainless Steel Processing: Always deploy a heavy-duty, chlorine-free EP (extreme pressure) compounding punching oil. For optimal performance, introduce the lubricant directly onto the active punch tip and substrate surface prior to initiating each stroke.

• Aluminum & Non-Ferrous Soft Alloys: Utilize a light-weight soluble emulsified oil or a high-purity wax-based lubricant. This alternative film isolates the chemical boundaries to prevent severe material galling, micro-welding, and matrix adhesion.

• Continuous Production Runs vs. Dry Operation: Operating with general machine oils or running completely unlubricated must be strictly prohibited during continuous multi-shift production. Radical frictional heat buildup induced by dry compression cycles can compromise tool hardness, dropping overall tool lifecycle metrics by 50% or more.

Establishing these proactive lubrication interfaces significantly minimizes progressive edge wear, typically extending functional punch and lower die lifecycle metrics by 2 to 3 times relative to unlubricated field parameters.

Hole Quality Troubleshooting

The ALAS Machinery quality control division observes that severe geometric deviations during punching—such as hole taper, ovality (out-of-roundness), or expanded bore diameters—typically develop from three separate field anomalies:

• Excessive Die Clearance: Utilizing an over-spec clearance allows the localized metal substrate to deflect or draw downward into the die matrix during penetration, creating an unacceptable tapered fractured edge.

• Insufficient Shank Rigidity: If the punch shank diameter is inadequately matched to the high compressive loading, the tool will experience radial deflection or flexing under load, inducing an ovalized geometry; upgrading to a reinforced heavy-duty shank stabilizes the path.

• Worn Die Retainers/Holders: Over-aged or degraded die blocks introduce severe mechanical backlash (slop), allowing the lower die to shift dynamically mid-stroke and throwing off concentricity.

For applications where tight geometric tolerances and high repeatability are paramount, we recommend running fully integrated, factory-matched tool sets engineered to maintain a strict operational alignment under 0.02mm.

➔ Reach out to our tech team for help dialing in your hole quality

Punch Regrind Guidelines

Restoring the micro-geometry of a worn shearing edge through systematic precision resurfacing minimizes compressive mechanical fatigue and ensures dimensional consistency across high-volume production lines. To guide maintenance technicians, the technical service division at ALAS Machinery enforces three quantitative baseline rules for the punch regrinding process:

• Single Regrind Incremental Depth (0.10–0.15mm): Each operational regrind path must remove only 0.10–0.15mm of tool steel from the working cutting edge. This volume is mathematically optimized to clear superficial fatigue lines or minor micro-nicks without wasting premium substrate depth.

• Maximum Cumulative Lifetime Removal (3mm): Do not allow total material removal from the punch active face to exceed a cumulative limit of 3mm over the entire service lifecycle of the tool. Exceeding this dimensional threshold curtails the absolute tool length, which compromises critical alignment matrices and disrupts synchronized stripping cycles.

• Expected Maintenance Lifespan (8 to 12 Regrinds): Implemented alongside proactive, routine inspection, our premium punches typically deliver 8 to 12 successful regrind sequences prior to physical scrappage, fluctuating with your exact substrate tensile strength and operating parameters.

Field Operation Protocol: Technicians must always utilize an industrial surface grinder equipped with an appropriate fine-grit abrasive wheel. It is mandatory to strictly replicate and maintain the factory-engineered shear angle during the entire sharpening procedure to guarantee balanced compressive forces during subsequent press runs.

Stainless & High-Strength Steel Punching Guide

Optimizing tool lifecycle during the processing of austenitic stainless steel or structural substrates exceeding a 450MPa tensile strength threshold requires a specialized engineering matrix. To prevent severe premature wear, the technical department at ALAS Machinery recommends implementing a three-tier field configuration:

• Advanced Substrate Selection: Substitute standard D2 tool steel with premium DC53 or S7 grades. These materials undergo proprietary vacuum heat treatments to achieve an optimal balance of structural hardness and localized toughness—targeting 60–62 HRC for DC53 and 56–58 HRC for S7 to mitigate micro-chipping under cyclic loading.

• Thin-Film PVD Coating: Integrate a Physical Vapor Deposition (PVD) coating such as TiN or TiCN. This layer significantly minimizes the coefficient of friction, effectively preventing severe material galling and cold-welding adhesion on the active cutting edges.

• Expanded Die Clearance (12%–15%): Expand the total double-sided die clearance to 12%–15% of the material thickness (in contrast to the standard 10% deployed for mild carbon steel) to attenuate compressive shock and counteract rapid strain hardening.

Metallurgical Note: Standard D2 steel is highly prone to premature failure in high-strength applications due to the presence of large, brittle primary chromium carbides. In identical heavy-duty cycles, traditional D2 matrixes demonstrate failure rates 2 to 3 times higher than our vacuum-optimized tool steel alternatives.

Individual Parts vs Complete Tooling Sets

The ALAS Machinery global procurement infrastructure supports both itemized single-component replacement and complete tooling assembly configurations to accommodate your facility's specific operational overhead and maintenance schedules. We break down our supply methodology into two standardized field approaches:

• On-Demand Individual Components: To minimize your tooling costs, there is zero obligation to purchase an entire system. If an isolated punch experiences wear or a single lower die cracks, we supply direct replacement piece-parts designed to seamlessly integrate with your existing inventory.

• Factory-Matched Tooling Sets: For tight-tolerance applications where concentricity and hole finish are paramount, we recommend utilizing fully matched assemblies. This options guarantees that the exact punch-to-die clearance is dialed in and validated at our manufacturing plant prior to shipment, yielding optimized shear cycles.

• Universal Tolerance Standards: Regardless of your purchasing profile, every standalone item is subjected to the identical, ultra-strict dimensional quality control as our comprehensive kits, ensuring total cross-compatibility with legacy tooling in your tool crib.

Whether optimizing a single workstation or restocking high-volume backup inventory, our estimation department is prepared to deliver flexible bulk or itemized pricing models. ➔ Get a quote for individual parts or complete sets

Lead Times & Urgent Orders

Operational turnarounds and shipping schedules fluctuate based on geometric complexity and production volume configuration. To maintain transparent logistics timelines across global steel fabrication supply chains, the planning department at ALAS Machinery operates under three standardized fulfillment brackets:

• Standard Stock Tooling (3–5 Working Days): Universal round and non-round shaped configurations matched to primary OEM machine holders are processed for dispatch within 3 to 5 working days, with global express air freight available to minimize international transit delays.

• Custom-Engineered & Non-Standard Dies (10–15 Working Days): Custom profile configurations require 10 to 15 working days following formal engineering drawing confirmation. This timeline incorporates precise CNC grinding, controlled vacuum thermal processing, and rigorous micro-geometric calibration.

• High-Volume Bulk Production (15–20 Working Days): Mass replenishment orders typically execute a 15 to 20 working day manufacturing window. In critical machine-down events, we offer localized split-shipment protocols—deploying partial fast-delivery batches to sustain your operational continuity.

Quality Assurance Protocol: Prior to logistics handover, every fulfillment batch is accompanied by a certified, comprehensive dimensional inspection report to verify adherence to strict technical tolerance bounds.

➔ Check current stock or request rush order options

Replacement Tooling Measurement Guide

The ALAS Machinery application engineering division specifies tracking two distinct sets of dimensional metrics to guarantee a seamless, zero-error fitment for your custom or standard replacement tooling. Please reference the following field verification parameters:

• Critical Punch Dimensions: Document the precise shank diameter, shoulder overall length (OAL), cutting edge diameter or geometric profile, and coupling thread specifications (pitch and diameter) if utilizing threaded retention rams.

• Critical Die Dimensions: Record the precision outer diameter (OD), total seating height, working matrix hole diameter or shape, and the exact step-shoulder configuration dimensions if running multi-tier stepped dies.

• Technical Document Support: Our technical center can supply a downloadable, formatted schematic inspection sheet to simplify your facility's verification process.

Alternatively, your facility may capture high-resolution photographs of the legacy tools with a calibrated digital caliper in position showing the dimensions. Please forward these files to our estimation team; our engineering department will cross-reference the geometry to verify the exact replacement part number and issue a verified quotation within one business day.

➔ Send photos of your tooling for free part matching

Standard Punch & Die Geometries

The ALAS Machinery standard product division supplies a comprehensive portfolio of heavy-duty replacement punches, dies, and shearing blades engineered to match a vast selection of universal hydraulic ironworker models. Designed for both miscellaneous metal fabrication and heavy structural steel operations, our standard inventory incorporates:

• Precision-Machined Tool Geometries: Round, square, oblong (oval), hexagonal, rectangular, and V-notch configurations engineered for immediate, zero-play field installation.

• Interchangeable Shearing Blades: Heavy-duty replacement blade kits custom-ground for flat bar shearing, angle iron cropping, and solid bar stock (round/square) slicing stations.

• Strict OEM Conformance: Every standard tool is manufactured to meet or exceed original equipment manufacturer dimensional metrics, ensuring out-of-the-box compatibility and flawless concentricity.

By consolidating your tooling requirements through our centralized technical manufacturing facility, your operation eliminates cross-brand sourcing friction and optimizes component traceability across multiple production lines.

➔ Check out our full standard punch and die catalog

Punch & Blade Material Selection Guide

Balancing abrasive wear resistance against core fracture toughness requires application-specific metallurgical pairing across each unique ironworker workstation. To secure dimensional stability under heavy cyclic compression, the standard technical inventory from ALAS Machinery operates under the following manufacturing steel directives:

• Punch Cores & Indexing Pins (S7 / DC53): Engineered from advanced shock-resisting S7 tool steel or ultra-high-toughness DC53. These components undergo computer-controlled multi-stage tempering to maximize compressive yield strength, ensuring stable hole concentricity with zero risk of structural deforming or face mushrooming.

• Shear & Notcher Station Blades (6CrW2Si / H13-1.2344): Fabricated from specialized tungsten-alloyed 6CrW2Si or premium modified H13 (DIN 1.2344) chemistries. This metallurgy effectively attenuates high-magnitude shock spikes and peak tonnage loads encountered when separating heavy structural angle iron, channel sections, or solid bar profiles, completely eliminating premature edge cleavage or chipping failures.

• Universal Drop-In Retrofitting: Every standard batch is precision-ground for immediate, zero-play field installation within major industrial equipment lines including Geka, Scotchman, Piranha, Kingsland, and Edwards, alongside comprehensive non-standard OEM/ODM custom fabrication from specific prints.

Implementing these targeted material matrices minimizes microstructural tool fatigue, extends machine component lifecycle safety, and delivers an optimal cost-per-cut ratio across multi-shift fabrication environments.

➔ Get material recommendations for your specific application

Punch Breakage & Die Wear Solutions

Premature tooling failure, such as sudden punch fracturing or accelerated die wear, typically compromises machine uptime and originates from one of four primary operational variables:

• Over-Capacity Loading: Exceeding the maximum material thickness or tensile strength rating specified for the specific tool geometry.

• Incorrect Die Clearance: Utilizing an out-of-spec punch-to-die tolerance, leading to structural compression or severe metal galling.

• Inadequate Lubrication: Operating without extreme-pressure boundaries, resulting in severe frictional heat buildup and edge degradation.

• Extended Operational Cycles: Running tools past their critical wear limits without routine sharpening, which induces severe stress concentrations.

To establish stable production parameters, we recommend maintaining strict sharpening intervals and implementing systematic alignment verifications. To streamline your facility's internal tool crib management, the ALAS Machinery manufacturing division offers permanent, high-resolution laser-etching for part numbers and dimensional specifications directly onto the shank of every punch and die block. This non-destructive identification system provides immediate part traceability on the shop floor and eliminates operator tooling selection errors during high-volume production changeovers.

➔ Browse our full tooling lineup

Punch Diameter to Material Thickness Ratio

The ALAS Machinery technical department enforces a strict mechanical baseline for standard punching operations: the target hole diameter must always be equal to or greater than the thickness of the metal substrate. To secure stable production and prevent catastrophic failure, we recommend adhering to the following structural parameters:

• The 1:1 Critical Ratio: A standard 10mm punch is engineered to process plate steel up to a maximum thickness of 10mm. Attempting to pierce material that exceeds the tool's diameter violates this fundamental mechanical boundary.

• Compressive Stress Spikes: Exceeding the 1:1 ratio forces severe compressive stress onto the punch tip that surpasses the tool steel's ultimate yielding threshold, resulting in sudden tool shattering or severe distortion to the stripper assembly.

• Heavy-Plate Engineering: For high-load structural applications approaching or slightly exceeding this technical limitation, standard tooling must be substituted with specialized, short-shank reinforced heavy-plate punches engineered to manage massive lateral and axial compression loads.

Uncertain if your impending manufacturing profile risks overloading your ironworker's press tooling? Contact our product support center to consult with a specialist. ➔ Reach out for custom heavy-plate punch support

Centering Nib on Standard Punches

Yes. All our standard round and non-round shaped punches are engineered with an integrated, precision-machined centering nib on the working face. This hallmark of ALAS Machinery tool design provides an accurate indexing point, allowing operators to seamlessly align the tool geometry with scribed layout lines or pre-drilled center-punch marks prior to actuating the hydraulic press cycle. Implementing an integrated nib delivers three primary operational advantages:

• Eliminates Tool Drift ("Walking"): It mechanically secures the center point upon initial contact, preventing the punch tip from drifting or deflecting across the metal substrate during compressive loading.

• Prevents Non-Axial Side Loading: By ensuring perfectly centered penetration, it mitigates uneven lateral forces and unbalanced stress distribution, significantly protecting the punch perimeter from premature micro-chipping.

• Extends Tooling Lifecycles: Maintaining balanced, perpendicular material displacement ensures optimal shear consistency, translating directly into a prolonged operational lifespan for both the punch and lower die.

Though a subtle design detail, this precision features drastically minimizes setup deviations and enhances part repeatability in high-volume structural fabrication.

➔ Check out our standard punches with centering nibs

Punch Sticking & Galling Solutions

Overcoming severe mechanical drag during the upward extraction phase is critical when processing ductile structural profiles or high-adhesive alloys. To eliminate structural binding, the application engineering division at ALAS Machinery optimizes press kinematics by isolating and neutralizing three severe friction variables:

• Friction-Induced Thermal Expansion: Operating at tight tolerances or under dry compression generates intense localized heating. This forces the punch tip to expand radiantly within the bore, creating a mechanical lockup during the return stroke.

• Precision Compound Back-Taper Geometry: To ensure unhindered tool withdrawal, our punches feature a micro-machined back-taper angle where the outer body diameter decreases incrementally toward the shank. This relief geometry completely eliminates vertical sidewall drag.

• High-Volume Anti-Adhesion Boundaries: For high-frequency continuous runs processing ductile materials like aluminum or galvanized plates, we integrate a cross-linked anti-adhesion boundary. Combining low-viscosity active drawing lubricants with specialized thin-film matrix modifications halts localized thermal fusion entirely.

Resolving extraction drag preserves the structural alignment of the machine ram, protects your mechanical stripping assembly from premature shock damage, and stabilizes continuous fabrication velocity.

➔ Browse our anti-galling back-taper punches with PVD coatings

Tool Steel Material Comparison

Selecting the correct metallurgical substrate remains the single most critical factor in controlling operational costs and driving tooling lifecycle stability. The production matrix below evaluates the engineering performance metrics of our universal tool steel selections under identical high-speed compression conditions:

To establish these performance benchmarks, the manufacturing plant at ALAS Machinery subjects every raw punch and die profile to a meticulous thermal processing sequence:

• Deep Cryogenic Stabilization: Sub-zero liquid nitrogen treatment is deployed to thoroughly eliminate unstable retained austenite, transforming it into premium martensite structures to neutralize internal residual stresses.

• Carbide Structure Refinement: Advanced multi-stage vacuum tempering evenly segregates and refines alloyed chromium and vanadium carbides, maximizing basic compressive shear limits.

• Extended Maintenance Intervals: This unified microstructural density drastically attenuates progressive edge radiusing and cleavage micro-cracking, maximizing operational runtime between precision regrinds under extreme mechanical loads.

➔ Compare our full material lineup

Custom Punch & Die OEM/ODM Services

The ALAS Machinery precision manufacturing division provides comprehensive OEM and ODM capabilities for non-standard, application-specific punch and die geometries. We support structural fabrication projects requiring custom profiles that extend beyond the standard round-hole catalog, including:

• Standard Non-Round Profiles: Oblong, hexagonal, square, and rectangular geometries designed for immediate integration into standard ironworker punch holders.

• Specialized Structural Cuts: Precision V-notch, cope-notching, pipe-saddling, and complex multi-radius profiles engineered to cross-reference specific architectural prints.

• Strict Dimensional Tolerance: Every custom component is CNC-machined and ground to your exact specifications, holding a strict dimensional tolerance within ±0.02mm to guarantee zero-play fitment and prolonged tool steel lifecycle.

Please submit your engineering drawings (CAD/DXF or PDF format) along with your material specifications to our technical center. Our estimating team will conduct a thorough feasibility review and provide a verified quotation within one business day.

➔ Send us your drawings for a custom quote

Shearing Tonnage Calculation Formula

The ALAS Machinery engineering department utilizes the standard industrial formula below to determine the precise press capacity required for specific punching and shearing applications:

Tonnage (Tons) = (Perimeter of Cut (mm) × Material Thickness (mm) × Shear Strength (MPa)) ÷ 9807

To ensure equipment longevity, we recommend reviewing these technical operational benchmarks:

• Real-World Reference Case: A Schedule 40 carbon steel pipe with a 60.3mm OD and a 3.91mm wall thickness typically requires approximately 18 to 22 tons of localized hydraulic force to execute a clean, single-pass shear.

• Safety Margin Recommendation: Always factor in a minimum 20% safety buffer above your theoretical calculated tonnage. This mitigates hydraulic shock, protects system valves, and extends tool steel lifecycle.

• Capacity Optimization: If the calculated tonnage approaches the maximum capacity of your ironworker press, our engineering team can custom-design bevel-angle or roof-top punches. These geometries reduce initial penetration resistance by up to 30%.

Uncertain if your current equipment meets the technical demands of an upcoming project? Please submit your material parameters and dimensions to our technical center for a complimentary, verified press-capacity analysis. ➔ Send your specs for a free tonnage assessment

Why Is My Ironworker Producing a Secondary Edge When Notching Pipe?

Here at ALAS Machinery, we find that a secondary shear plane or double-edge defect during pipe notching typically stems from two primary root causes:

• Tooling Misalignment: Loose coupling nuts, worn guiding systems, or shifting components during the stroke can compromise concentricity and cause dimensional drift.

• Insufficient Die Clearance: Operating with a clearance that is too tight forces the punch to generate a secondary tear on the pipe sidewall rather than a clean, single-pass shear.

We recommend implementing the following technical procedures to resolve this issue:

• Measure Tool Runout: Shut down the equipment and utilize a dial indicator to check system alignment. Total runout must be maintained under 0.05mm (0.002") to prevent geometric distortion.

• Optimize Clearance for Stainless Steel: When processing heavy-walled stainless steel pipe, expand the total clearance to 18%–20% of the wall thickness to reduce tonnage load and minimize work-hardening.

• Upgrade to a Permanent Solution: To eliminate manual alignment errors entirely, our Self-Aligning Punch & Die Series features precision-ground alignment keys, eliminating the need for repetitive operator adjustments during changeovers.

➔ Check out our self-aligning notching tooling

Warping Causes & Anti-Deformation Solutions

The ALAS Machinery application engineering team identifies that material warping typically occurs when the localized punch force exceeds the substrate's yield strength prior to the initiation of the actual shear fracture. This defect is common when processing soft alloys like 6061 aluminum, or thin-walled tubing lacking internal structural support. We recommend two standard technical adjustments to mitigate deformation:

• Calibrate Punch Penetration Depth: Optimize your machine's stroke travel so the punch tip enters the lower die by no more than 1/16" (1.6mm). Excessive penetration unnecessarily stresses surrounding material.

• Implement Rigid Material Restraint: Ensure the setup utilizes heavy-duty urethane strippers or integrated mechanical hold-downs to maintain uniform flatness against the die block face throughout the cycle.

For severe structural profiles, we custom-engineer specialized pipe notching dies equipped with contoured mandrel inserts and built-in blank holders. This architecture distributes clamping forces symmetrically, enabling us to hold strict geometric tolerances—maintaining warpage within 0.1mm per meter, even on thin-walled structural geometries.

➔ Check out our custom anti-warp notching dies

Dull Tooling Symptoms & Maintenance Guide

Operating an ironworker with dull or degraded tooling compromises piece-part quality while placing excessive, non-axial stress on your machine's hydraulic cylinder and structural frame. To protect your equipment, we recommend monitoring production for these four primary indicators of tooling wear:

• Acoustic and Vibration Shifts: A distinct change in operational noise—where a clean, high-frequency "snap" degrades into a heavy, low-frequency thud accompanied by localized machine shudder.

• Excessive Burr Height (>10%): Burr formation that exceeds 10% of the base metal thickness indicates significant cutting-edge degradation, requiring immediate tool intervention.

• Cutting-Edge Micro-Chipping (0.2mm–0.3mm): Visible micro-fracturing, scoring, or edge breakdown spanning more than 0.2mm to 0.3mm across the working geometry of the punch tip.

• Hydraulic Tonnage Spikes (>15%): A measurable 15% or greater increase in pressure gauge readings required to punch identical material profiles, indicating the press is working beyond optimal design parameters.

Our standard punches and dies are engineered from premium H13 and DC53 tool steels to optimize runtime between maintenance cycles. However, when edge radiusing progresses beyond these specified thresholds, the tooling should be pulled and sent out for a professional precision regrind before catastrophic micro-cracking develops.

➔ Shop our long-life notching dies and heavy-duty punches

Getting Your Die Clearance Right

Maintaining a precisely calibrated total (double-sided) die clearance is the foundational parameter governing tooling service life and hole geometric accuracy. To prevent severe edge degradation under heavy cyclic loads, the engineering division at ALAS Machinery calculates optimized clearance boundaries for every field setup. Running an under-spec clearance causes rapid frictional heat buildup, leading to punch binding and premature micro-chipping. Conversely, excessive clearance induces severe plastic deformation, high burr formation, and out-of-spec hole warping. We pinpoint your optimal clearance based on the absolute tensile strength and elongation properties of the specific metal substrate:

Need technical assistance configuring precise punch-to-die tolerances for your specific hydraulic press? Reach out to our application support center—our engineering specialists are prepared to review your parameters. Contact our support team for custom clearance calculation
