Wear-resistant reinforcement fixing blade for PHC pipe piling machine

Share to:

Reinforcement Fixing Blades for Concrete Pipe Piling Machines

Port:
Nanjing, China
Payment Terms:
L/C, T/T, Money Gram
Production Capacity:
10000PCS/Year

Availability:

Quantity:



Inquire Add to Basket

Product Description

Core Special Accessories for Prestressed Steel Bar Processing of Concrete Pipe Pile Driver

The core special accessories for prestressed steel bar processing of concrete pipe pile drivers are fixed blades, movable blades, heading dies and steel bar clamps. They are used in all steps of processing special prestressed steel bars for pipe piles, including cutting, end upsetting, tensioning and clamping.

The quality of these accessories (precision, material and adaptability) directly affects how well the steel bars are processed. This, in turn, impacts the prestressed anchoring effect, structural strength and qualified rate of finished pipe piles.

1. Fixed & Movable Blades: Cutting Accessories for Prestressed Steel Bars

Fixed and movable blades are special wear parts for cutting steel bars. They are designed for small-diameter, high-strength prestressed steel bars (not general pipe pile cutting tools).

Key Functions

The fixed blade provides stable support; the movable blade moves back and forth with hydraulic power.
They work together to cut PC steel bars and prestressed steel wires smoothly (no burrs, no bevels).
Ensure accurate cutting length and avoid problems that affect subsequent processing (upsetting and tensioning).

Applicable Steel Bars

Mainly used for common prestressed steel bars in pipe pile production: Φ7.1, Φ9.0, Φ10.7, Φ12.6mm.

Material

Cutting steel bars requires high wear resistance and edge strength. D2 cold work die steel is usually used.

2. Heading Dies: Forming Tools for Steel Bar End Upsetting

Heading dies are the core forming tools for the pipe pile driver’s heading mechanism, and are key for prestressed steel bar anchoring.

In pipe pile production, the end of the steel bar must be upset (pressed to form a "heading").
This heading ensures the steel bar connects reliably with the anchor during tensioning.
The precision of the die’s cavity directly determines the quality of the heading, which affects the safety of prestress tensioning.

3. Steel Bar Clamps: Positioning Tools for Upsetting

Clamps are special positioning tools for prestressed steel bar upsetting, used with heading dies. Their main role is to fix the steel bar and ensure it aligns with the die cavity.

Key Functions

Positioning: Ensure the steel bar end and die cavity are aligned (deviation ≤0.03mm). Avoid defects like eccentric or flat headings.
Clamping: Keep the steel bar fixed under high upsetting pressure (50~200kN). Ensure the heading length and diameter meet design requirements (1.5~2 times the steel bar diameter).
Protection: The clamp surface fits the steel bar tightly to avoid damage or hardening, and keep the steel bar’s mechanical properties intact.

Summary of Core Accessories

Fixed/movable blades: Wear parts for cutting; need regular replacement.
Heading dies: Forming tools that affect prestressed anchoring safety.
Clamps: Positioning tools that ensure uniform prestress distribution in pipe piles.
All four accessories work together to ensure high-quality steel bar processing, from cutting to upsetting and tensioning.

Reinforcement bar clamp for precast pipe piles 9

Reinforcement cutting blades for precast pipe piles4 Reinforcement bar clamp for precast pipe piles 5 Precast pipe pile accessories15
